Product Introduction:

This machine is developed with the method of mixed powder jetting, which is widely applied for the materials grinding for the trades of pharmaceutics, chemical, and foodstuff etc.

Working Method:

This machine has a simple structure and is easy to be installed and dismantled and cleaned with the features of stable running, convenient moving, low noise, and high grinding efficiency etc.

This machine is a high speed running one. The target material is smashed by the cutting and grinding of high speed knifes, which the figure and size of knifes can be selected in accordance with different material and the size of granules can be acquired by screen changing or speed-regulating.

Technical Data:

Model	LYFM-8	LYFM-16	LYFM-32
Capacity(kg/h)	10-100	50-300	100-500
Output size(mesh)	12-120	12-120	12-120
Motor power(kw)	3	7.5	11
Speed(rpm)	2350-4360	1000-2400-4400	1000-2400-4400
Dimension(mm)	1050×600×1600	1100×860×1520	1280×950×1600
Weight(kg)	150	250	320
